AIDA JAPAN MODEL: PD-30
‘H’ FRAME DOUBLE CRANK PRESS
AIDA JAPAN
MODEL: PD-30
SKU # 1478
Brief Specifications/ Details
- Cap : 300Tons
- Stroke : 350mm
- Die Height : 720mm
- Adjustment : 100mm-Electrical
- SPM : 40
- Slide : 2500 x 1000mm
- Bolster : 2600x1360mm
Accessories
With Die Cushion
Other Details (Approx)
- Clutch : Dry
- Main Motor : 45KW
- Power Required : 220V/80KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 9’-0”, L-R: 21’-0”, HT: 17’-6”
- Machine Weight : Tons
