C-FRAME SINGLE CRANK PRESS

AMADA JAPAN
MODEL : TP-2000-X2

SKU # 1579

Brief Specifications/ Details

• Cap : 200Tons
• Stroke : 200mm
• Die Height: 450mm
• Adjustment : 110mm
• SPM :35
• Slide : 850 x 630mm
• Bolster : 1450 x 850mm

Accessories

With Die Cushion

Click Here For Video

 Other Details (Approx)

• Clutch : Wet
• Main Motor : KW
• Power Required : 415V/20KVA Phase : 3
• Air Required : 5.5/sqcm
• Machine Size : F-B: 9’-10”, L-R: 6’-4”, HT: 14’-0”
• Machine Weight : Tons
